Application of a Single-Glass MINIMAL System

Partition Walls with single glazing:

Single glazed partition walls are preferred because they are more economical and easier to install.

They are usually manufactured as 10 mm "tempered glass"..

As there is only Single glazed, there is no possibility to use "blinds". Instead, it can be covered with a strip of film up to 130-140 cm, leaving a gap of 30-40 cm from the bottom. It is also possible to apply it in different sizes and shapes.

If the installation is to be accelerated and travel costs are taken into consideration, the profiles are first laid in accordance with the project, and the "door frames" are placed in their places in the system in accordance with the project.

Glass measurements are taken and ordered. When the glass arrives from the glass factory, it is installed.

If the glass is 4+4 or 5+5 "templess laminated", the installation can be completed immediately, except for the door glass. Only "door windows" are waited for.

In single-glazed systems, different options can be obtained with glass qualities. For example, sound insulation can be achieved by using "acoustic laminated" glass. Sound insulation up to 38 DB is possible, although not as much as double glazing.

If quality glass is desired, extra clear glass can be used.


When acoustic glass is used, if the partition wall is installed on a "raised floor", a 10 cm wide sound barrier filled with rockwool should be installed under the floor and at the same time a sound barrier filled with rockwool should be installed on the ceiling up to the ceiling where the partition walls overlap.

In this case, it would be beneficial to manufacture glass doors as "double glazed structural".

In order to create an acoustic system, it is necessary to take additional measures in "glass doors", to put sound insulation wicks on the door frames and to install sound barriers under the doors.

In all "partition walls", the important point to be considered is the choice of "accessory brand". There are companies that have a say in this field in the world. By using the "handles, locks and hinges" of these brands, malfunctions are minimized, thus eliminating the need for servicing due to accessory failures.

Apart from these issues, our architects may request that aluminum profiles be painted with "electrostatic powder paint" in various colors to be compatible with other units in the decoration.

At this point, if you say, "after spending so much and making our choices carefully, is this the right thing to do?", we have to think about it.

The recommendation is to make an acoustic calculation for the whole system.

When acoustic calculation is made in partition walls, you can get rid of unnecessary thicknesses.

In addition, glass thicknesses in double glazed systems may not be equal as a result of the calculation (8 mm + 6 mm).

Even according to the result of the calculation; In some offices, you may need to use glass choices as 4 + 4, 5 + 5, 6 + 6 mm laminated glass.

These glasses can be manufactured as tempered, grinded. In addition, specially manufactured Acoustic Laminated glasses can be used for the same thicknesses.
